Pb RoHS
2.5 x 2.0 x 0.95 mm 32.768kHz CERAMIC
SURFACE MOUNT CRYSTAL OSCILLATOR
ASDK Series
Compliant
OUTLINE DRAWING:
PIN
1
2
3
4
2.5 x 2.0 x 0.95 mm
| | | | | | | | | | | | | |
FUNCTION
Tri-state
GND
Output
Vdd
|
Note: Recommend using an approximately 0.01uF
bypass capacitor between PIN 2 and 4.
Dimensions: inches (mm)
TAPE & REEL: (1,000pcs/reel)
Dimensions: mm
REFLOW PROFILE
Need a test socket for the ASDK Series? To view
compatible PRECISION TEST & BURN-IN SOCKETS
for these parts, click here. AXS-2520-04-07
ISO / QS
ABRACON IS
ISO 9001 9001:2008
CE RTIFIED
ATTENTION: Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for
Commercial, Industrial and, where designated, Automotive Applications. Abracon’s products are not specifically
designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requiring high
reliability where component failure could result in loss of life and/or property. For applications requiring high
reliability and/or presenting an extreme operating environment, written consent and authorization from Abracon
Corporation is required. Please contact Abracon Corporation for more information.
Visit www.abracon.com for Terms & Conditions of Sale Revised: 06.10.11
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000 | fax 949-546-8001 | www.abracon.com
